Hot sale SAILAI SLA108 100TON108TON 128TON injection moulding machine for sale plastic molding machinery price

Injection molding machines offer several advantages over other manufacturing processes, including:
1.High efficiency: Injection molding machines can produce large quantities of products in a short amount of time, making it a highly efficient manufacturing process.
2.Versatility: Injection molding machines can produce a wide range of products with varying sizes, shapes, and complexities, making it a versatile process for different industries.
3.High accuracy and repeatability: Injection molding machines can produce products with high accuracy and consistency, ensuring that each product is manufactured to the desired specifications.
4.Low labor costs: Injection molding machines can be automated, reducing the need for manual labor and lowering labor costs.

5.Material variety: Injection molding machines can process a wide range of materials, including thermoplastics, thermosets, and elastomers, allowing for greater flexibility in product design and functionality.
6.Reduced waste: Injection molding machines can reduce waste by recycling excess plastic material, making it an environmentally friendly manufacturing process.
Overall, injection molding machines are a highly efficient, versatile, and accurate manufacturing process with a range of advantages over other manufacturing methods.

Availability:
Quantity:
  • AMAN

Product Description

MACHINE MODEL
SLA138
INJECTION UNIT
A
B
C
SCREW DIAMETER (MM)
32
35
38
SCREW L/D RATIO (L/D)
24.1
22.1
20.3
INJECTION PRESSURE(Mpa)
262
219
186
SHOT VOLUME(CM³)
140
168
198
INJECTION WEIGHT (G)
124
148
175
INJECTION RATE(CM³/S)
79
95
112
SCREW SPEED(RPM)
229
INJECTION STROKE(MM)
175
CLAMPING UNIT

CLAMPING FORCE(KN)
1080
TOGGLE STROKE(MM)
325
SPACE BETWEEN TIE-BARS(MM)
360X330
MAX.MOLD HEIGHT(MM)
360
MIN.MOLD HEIGHT(MM)
150
EJECTOR STROKE(MM)
91
EJECTOR TONNAGE(KN)
38
OTHERS

MAX.PUMP PRESSURE(Mpa)
16
SERVO MOTOR POWER(KW)
11
HEATER POWER(KW)
6.8
HEATING SECTION(part)
3+1
OILTANK CUBAGE(L)
190
MACHINE DIMENSIONS(M)
3.90X1.10X1.75
MACHINE WEIGHT(T)
2.8
